Secondary Gluing Machine

Features
  • After gluing roller surface tempering and inner bore processing, the surface of the gluing roller is dynamic balance finely ground and engraved with 32 lines of corrugated mesh with uniform gluing and less glue consumption.
  • The gluing roller rotation is controlled by variable frequency motor, which ensures that the linear speed of the roller is synchronized with the double facer, and can operate independently.
  • Electric adjustment of glue amount with digital display. Automatic circulation of glue supply can avoid glue precipitation to ensure stable viscosity.
  • Adopts air-press paper structure and electric motor to adjust the clearance. The upper, middle and lower layers are driven by independent frequency motor.
  • Measure the speed signal of double facer to realize synchronous operation. Adopts man-machine interface display with simple and convenient operation.
  • The amount of glue can be adjusted automatically with production speed. Besides, can also be manual fine-tuning in the automatic mode, easy to operate.
Regular technical parameters:
  • Pre-heater cylinder temperature: 160-200℃
  • Steam pressure: 0.8-1.2Mpa
  • Air pressure: 0.4-0.7Mpa
Rollers diameter parameters:
  • Glue roller diameter: ￠320mm
  • Stick roller diameter: ￠153mm
  • Lower pre-heater roller diameter: ￠402mm
  • Upper pre-heater roller diameter: ￠374mm
  • Conveying roller diameter:￠110m
Parameters of motor and electric appliance:
  • Glue roller main motor: 3kW
  • Glue adjustment motor: 250W
  • Press roller clearance adjustment motor: 250W
  • Glue pump motor: 2.2kW
